1. The maintenance-free, high-power, brushless AC traction motor has excellent acceleration, performance, good climbing ability, and low heat generation.
2. The CURTIS control system provides accurate, stable, and more cient control of the AC traction motor.
3. The CAN-BUS structure makes the communication between the different parts on the truck faster and more reliable.
4. The truck uses the regenerative braking system to prevent the pallet truck from sliding down a ramp.
5. The switches, controller, connectors, and battery plug are all parts from industry known suppliers to ensure reliability, performance, and ease of service.

1. The floating suspension driving system automatically adjusts depending on the load to provide su cient power to the driving wheels.
2. Thanks to the tiller’s design, all operations can be completed with one hand.
3. When in turtle mode, the truck can be driven slow easily, and more accurately.
4. The pallet truck’s design is optimized for great visibility and easy operation in narrow aisle applications.
5. Customer can choose a variety of different lengths and outside fork widths to fit their needs.

1. The A Series Pallet Jack features three braking types. These include releasing, reversing, and emergency braking. This ensures the operators safety.
2. The pallet jack won’t slip on a grade to ensure safe operation.
3. When pressed, the emergency button on the tiller head immediately cuts power to the pallet truck to help keep the operator safe.
4. The lifting limit switch is designed to help protect loads from damage.

1. Integrated Battery Management System (BMS) continually monitors energy management and ensures reliable operation.
2. HANGCHA provides these Lithium Iron Phosphate (LiFePO4 ) battery packs with up to a 5 year or 10,000 hour warranty.
3. See warranty certificate for specific warranty information on the Lithium Iron Phosphate battery packs.

1. With a high-strength steel frame structure, the truck’s frame has a large residual load capacity and a long service life.
2. The electrical system uses waterproof connectors and protection on the wires and cables to improve the electronic’s reliability.
3. The unique floating suspension system ensures that the drive wheels grip and provide smooth operation.
4. The pump motor has a longer service life and saves energy because of the electronic lifting limit switch on the motor.
5. The low noise and vibration hydraulic power unit enables stable and reliable lifting and lowering.
6. The punched formed forks provide higher strength and are impact resistant.
7. The pallet truck is equipped with tip guides to improve operational effciency.
8. The H-type mast profile section provides better load stability.
9. The power plug is fixed on the pallet truck’s body to avoid damage when installing the battery.
10. The new design drive system prevents thedrive motor from accompanying the tiller’s rotation. This keeps all of the drive motor’s cable connections from bending.
11. Using a non-contact proximity switch provides reliable operation and a longer service life.

1. The brushless AC drive motor is maintenance-free. This significantly reduces the operating costs of the pallet truck.
2. The maintenance hatch opens to allow for easy access to all of the truck’s components.
3. The shafts are equipped with lubricated sleeves and oil cups to facilitate maintenance and promote a long service life.
