XH1
XH Series High Voltage Lithium-ion Pneumatic Forklift
4,000-75,000lbs lifting capacity
FEATURES

/ With the inherited exterior design of the dedicated XC lithium battery forklift and a smooth and sturdy profile, the whole vehicle is impact, elegant, stylish, sturdy and powerful.

/ Equipped with a lock, the hood designed to be back-flipped open to and facilitate charging, liquid replenishment and maintenance.
/ The water tank lid can be removed quickly and easily without a tool to enable a large operating area for cleaning and maintenance.

/ The wide-view mast with optimized design is unlikely to obstruct the operator’s line of sight. The enlarged opening size of the fork carriage enables a wider view, a large operation space, and excellent ergonomic design.
/ The multifunctional color-screen instruments are designed to have graphical interfaces and display data clearly. Three speed gears are provided to adapt to different operating environments. The interfaces can be switched to be shown in Chinese and English to meet the needs of customers at home and abroad.
/ The enlarged brake pedal and appropriate regenerative braking function can effectively reduce the driver’s fatigue.

/ Both the drive and operating systems are vehicle-grade permanent magnet synchronization systems, equipped with a high-speed ratio gearbox with a driving speed, upslope degree and acceleration performance rival that of internal combustion vehicles, and the environmental performance better than that of internal combustion vehicles.
/ The vehicle uses an overall controller, and the drive system and operating system are assembled with motors electronically controlled, to form a highly independent light, efficient, and intelligent drive system.
/ The vehicle’s 307V high-voltage platform is equipped with a long-lasting large-capacity lithium battery, which is powerful, efficient and energy-saving, adopts a super-fast charging technology that enables a short charging time.
/ A water-cooling system with a good heat dissipation effect is used on a new energy forklift for the first time, so that the forklift can absolutely carry out long-time and high-intensity operations as internal combustion forklifts.

detail-1

Multifunctional color-screen instruments

detail-2

Wide-view mast

detail-3

Equipped with a lock, the hood designed to be back-flipped open to and facilitate charging, liquid replenishment and maintenance.

STANDARD FEATURES
  • Multi-function color-screen combination instrument
  • Large integral rubber pedal pads
  • Standard duplex mast, fork, fork carriage and load backrest
  • Stamped iron hood, stamped iron side plates
  • Stamped stainless steel boarding step
  • The gas spring of the hood with a touch-proof mechanism
  • Handbrake with a touch-proof mechanism
  • Integrated fuse box
  • Charging muzzle meeting national standards
  • Reverse buzzer
  • Lithium battery pack
  • Low temperature electric heating systems
  • Permanent magnet AC traction motor controller
  • Permanent magnet AC oil pump motor controller
  • DC-DC power supply
  • VCU controller
  • MSD maintenance switch
  • Emergency power off switch
  • Mileage display, operating time display
  • Load sensing steering system
  • Turning deceleration function
  • Soft landing
  • SPE power selection
  • Electronic water pump
  • Electronic fan
  • Heat dissipater
  • Expansion tank
  • Double multi-way valve
  • Low noise gear pump
  • Traction pin
  • LED combination headlights, LED rear combination three-color taillights
OPTIONS
  • Solid tire
  • Left and right rear-view mirrors
  • Reversing video
  • Front/rear blue lights
  • Rear operation lights
  • Lithium battery charger
  • Cold storage
  • Reverse armrest (with a horn button)
  • OPS system
  • Triple multi-way valve
  • Quadruple multi-way valve
  • Quintuple multi-way valve
  • Widened / heightened load backrest
  • Widened fork carriage
  • Forks of other lengths
  • Free duplex mast
  • Free triplex mast
  • Built-in side shifter
  • Accessories for other specifications
  • Grammer MSG531 suspended seat
  • Start with a PIN code or by swiping a card
  • Coloring solid environmentally friendly seamless tire
  • Fork ascending buffering
  • Fingertip control system
  • Toolbox, folder
OTHER IMAGES
